BWD ANSI Code

BWD ANSI is a T8 lamp with a Wire Leads base operating at 35.7 watts and 8.5 volts. It has a Clear finish. The average rated life is 150 hours. See the specifications table below for complete technical details, dimensions, compatibility information, and operating characteristics for ANSI BWD lamps.

Electrical Specifications

Amps4.2
Volts8.5
Watts35.7

Photometrics

Light Center Length (LCL)41
Lumens700

Physical Characteristics

BaseWire Leads
Bulb ShapeT8
FilamentC-8
FinishClear
Max Overall Length (MOL)79 2/5

Operating Characteristics

Burn PositionVBD
Life Hours150

General Information
Lamp CodeBWD
Code TypeANSI
Specification ReferenceANSI-SR24F2002

T8 Shape

T8
Diameter Designation8/8"
Glass Diameter 1" (1.0")
Shape CodeT
Shape ClassificationTubular

C-8 Filament

C-8
Coil TypeC - Single Coil

Cross Reference Part Numbers

BrandMPNDescriptionAvailability
Microlites8.5-35.7-67C
Canimpex8.5-35.7-67C

BWD may also be listed as:
006-0501 COLEMAN006-0501 PERKIN-ELMER14-376-216 COLEMAN256010U MICROLAMP
35.7T8DCPAX8.5V4.2A-T8-P15D30-CLEAR-8.5V4.2A/T8/P15D30/CL/8.5V4.2AMP-T8-P15D30-8.5VOLT
4.2AT8DCP/CL8.5V4.2AT8DCP8.5V8.5V/4.2A/P15D30/T8BW-BWD
BWD ANSIBWD ASABWD INTERLIGHTBWD MICROLAMP
BWD-8.5V ANSIBWD-8.5V ASABWD-8.5V-35.7W ANSIBWD-8.5V-35.7W ASA
BWD-8.5V-4.2ABWD-8.5V-4.2A ANSIBWD-8.5V-4.2A-P30D-T8-C8-CLEAR-700L-150HBWD-8.5V-MODIFIED/8.5V/35.7W/WL ANSI
BWD-8.5V/8.5V/35.7W/P15D30A ANSIBWD-8.5VOLT ANSIBWD-8.5VOLT ASABWD-MODIFIED
BWD-MODIFIED-8.5VBWD-MODIFIED-8.5V-35.7WBWD-MODIFIED/8.5V/35.7W ANSIBWD-MODIFIED/8.5V/35.7W/WL ANSI
BWD/8.5V/35.7W/P15D30 ANSIBWD/8.5V/35.7W/P15D30A ANSIC-006-0501 CIBAC-006-0501 CIBA-CORNING
C-006-0501 CORNINGC006-0501C006-0501-PEC006-0501-PERKIN-ELMER
I/8.5V/35.7W/P15D30/T8/AXI/8.5V/35.7W/P15D30/T8/AX/150HI/8.5V/35.7W/P15D30/T8/AX/150H/35.7T8DCPAX8.5VI/8.5V/35.7W/P15D30/T8/AX/150H/BWD
I/8.5V/35.7W/P15D30/T8/AX/35.7T8DCPAX8.5VI/8.5V/35.7W/P15D30/T8/AX/BWDI/8.5V/35.7W/P15D30/T8/C8/150HI/8.5V/35.7W/P15D30/T8/C8/150H/BWD
I/8.5V/35.7W/P15D30/T8/C8/BWDI/8.5V/35.7W/P15D30A/T8/AX/150HI/8.5V/35.7W/P15D30A/T8/AX/150H/BWDI/8.5V/35.7W/P15D30A/T8/AX/BWD
I/8.5V/35.7W/P15D30A/T8/C8/150HI/8.5V/35.7W/P15D30A/T8/C8/150H/BWDI/8.5V/35.7W/P15D30A/T8/C8/BWDI/8.5V/35.7W/P15D30A/T8/CL/150H
I/8.5V/35.7W/P15D30A/T8/CL/150H/BWDI/8.5V/35.7W/WL/T8/C8I/8.5V/35.7W/WL/T8/C8/BWD-MODIFIEDI/8.5V/35.7W/WL/T8/CL
I/8.5V/35.7W/WL/T8/CL/BWD-MODIFIEDI/8.5V/4.2A/P15D30/T8/150HI/8.5V/4.2A/P15D30/T8/AX/150HI/8.5V/4.2A/P15D30/T8/PHOTO
I/8.5V/4.2A/P15D30/TUBE/150HPERKINELMER-006-0501PH/4.2A/T8/P15D30/CL/8.5VSP35.7T8DCPAC8-8.5V
SP35.7T8DCPAC88.5V-BWDSP35.7T8DCPACL8.5VSP35.7T8DCPACL8.5V-BWDSP35.7T8DCPAX8.5V
SP35.7T8DCPC8-8.5VSP35.7T8DCPC88.5V-BWDSP35.7T8DCPCL8.5VSP35.7T8DCPCL8.5V-BWD
SP35.7T8P15D30AC8-8.5VSP35.7T8P15D30AC88.5V-BWDSP35.7T8P15D30ACL8.5VSP35.7T8P15D30ACL8.5V-BWD
SP35.7T8WLC8-8.5VSP35.7T8WLC88.5V-BWD-MODIFIEDSP35.7T8WLCL8.5VSP35.7T8WLCL8.5V-BWD-MODIFIED
