G/35 LIF Code
G/35 LIF is a T18 lamp with a PX28s base operating at 6.5 watts and 6.5 volts. It has a Clear finish. The average rated life is 500 hours. See the specifications table below for complete technical details, dimensions, compatibility information, and operating characteristics for LIF G/35 lamps.
Electrical Specifications | |
| Amps | 1.48 |
|---|---|
| Volts | 6.5 |
| Watts | 6.5 |
Photometrics | |
| Light Center Length (LCL) | 31.5 .5 |
|---|---|
| Lumens | 117 |
Physical Characteristics | |
| Base | PX28s |
|---|---|
| Bulb Shape | T18 |
| Filament | FC-8Z |
| Finish | Clear |
| Max Overall Length (MOL) | 74 |
Operating Characteristics | |
| Burn Position | H +90-45° |
|---|---|
| Life Hours | 500 |
General Information | |
| Lamp Code | G/35 |
|---|---|
| Code Type | LIF |
| Specification Reference | Class G - Exciter |
PX28s Base |
 |
Cross Reference Part Numbers | |||
| Brand | MPN | Description | Availability |
| LIF | G/35 | ||
