ASL XM1000HSC/G - 1000W - Short Arc Xenon Lamp
This product is an Advanced Specialty Lighting XM1000HSC/G short arc xenon bulb.
ASL XM1000HSC/G - analog short-arc lamp.
Replacement for LTI LTIX-1000W-HSC, OSRAM XBO 1000W/HSC OFR, Christie CXL-10SC, USHIO UXL-10SCB, Yumex YXL-10S, Superior Quartz SX10009C.
Cross Reference Part Numbers
- LTI LTIX-1000W-HSC
- OSRAM XBO 1000W/HSC OFR
- Christie CXL-10SC
- USHIO UXL-10SCB
- Yumex YXL-10S
- Superior Quartz SX10009C
About Advanced Specialty Lighting
Founded in 2003, Advanced Specialty Lighting manufactures lighting for a wide range of applications. These include microscopes, medical equipment, graphic scanners, commercial film projectors, skytracker spotlights, and solar simulation, among others. The company is headquartered in Chicago, Illinois, with manufacturing plants in the United States, China, and Poland.
| Anode (+) Base (mm) | 27-11 |
|---|---|
| Burn Position | H±20° V±20° |
| Cathode (-) Base (mm) | 27-5/16-18unc-2A |
| Current Control Range (A.D.C.) | 30-55 |
| Lamp Type | Short Arc Xenon |
| Lumens | 33000 |
| Rated Current (A.D.C.) | 50 |
| Volts | 20 |
| Warranty | 100% Credit: 0/2500 |
| Watts | 1000 |
| Brand | Advanced Specialty Lighting |
|---|---|
| MPN | XM1000HSC/G |
| HS Code | 853941 |
